2026 Bronco 17-Inch Beadlock-Capable Wheels: Installation and Torque Specs
Ever had a tire slip off the bead at 12 PSI in the middle of a rock garden?
That’s the moment beadlock wheels earn their price. The 2026 Bronco offers 17-inch beadlock-capable wheels on several trims. Here’s exactly how to install them and what torque specs you need.
TLDR: The 2026 Bronco’s factory beadlock-capable wheels come with beauty rings installed. To convert them to functional beadlocks, you need Ford Performance beadlock ring kits. Lug nut torque is 135 Nm (100 lb-ft). Beadlock ring bolts require a three-stage torque sequence ending at 65 Nm (47.9 lb-ft).
Key Takeaways:
- Lug nut torque: 135 Nm (100 lb-ft) for M12 x 1.5 studs
- Beadlock ring bolt torque: 65 Nm (47.9 lb-ft) in three stages
- Factory beauty rings must be removed before tire service or beadlock conversion
- Ford Performance beadlock rings are for off-road use only
- Re-torque beadlock bolts after 500 miles of driving
What Are Beadlock-Capable Wheels?
Why does Ford sell wheels that aren’t fully beadlocks from the factory?
The answer is simple: street legality. True beadlock wheels clamp the tire bead between the wheel and a ring. This keeps the tire seated even at very low air pressure. But on public roads, true beadlocks aren’t legal in most places. The bolts can loosen, and the design isn’t DOT-approved for highway use.
Ford’s solution is beadlock-capable wheels. They look like beadlocks. They have the bolt holes. But from the factory, they come with a beauty ring — a trim piece that covers the bolt holes but doesn’t actually clamp the tire.
You remove the beauty ring and install a functional beadlock ring when you want to air down for serious off-roading.
Which 2026 Broncos Have Them?
The 2026 Bronco offers 17-inch beadlock-capable wheels on several configurations:
- Badlands: Available with 17-inch Carbonized Gray-painted aluminum beadlock-capable wheels
- Raptor: Available with 17-inch dark carbonized gray beadlock-capable forged wheels as part of appearance packages
- Outer Banks: Available with 17-inch Black High Gloss-Painted Aluminum with Black Beauty Ring Beadlock Capable Wheels
The Bronco Raptor uses a different bolt pattern than standard Broncos. Make sure you buy the correct ring kit for your model .
Beauty Ring vs. Functional Beadlock
| Feature | Beauty Ring | Functional Beadlock Ring |
|---|---|---|
| Purpose | Cosmetic trim | Clamps tire bead |
| Street Legal | Yes | No (off-road only) |
| Torque Spec | Ford spec (not published) | 65 Nm (47.9 lb-ft) |
| Bolts | Factory installed | 24 per ring |
| Tire Pressure | Standard | Can run very low PSI |
The beauty rings on Bronco wheels are held on with Torx bolts. Forum users report they strip easily, so use hand tools and take your time .
Installation: Step-by-Step
Tools You’ll Need
- Torque wrench (capable of 65 Nm / 48 lb-ft)
- 13mm socket for beadlock ring bolts
- Torx socket set (for beauty ring removal)
- Tire soap or mounting lubricant
- Valve stem core tool
- Jack and jack stands
- Wheel chocks
Step 1: Remove the Wheel
Loosen the lug nuts while the Bronco is on the ground. Then jack it up and remove the wheel. The lug nuts require 135 Nm (100 lb-ft) of torque when you reinstall .
Step 2: Remove the Beauty Ring
The factory beauty ring uses Torx bolts. Remove them carefully. Don’t use power tools — the bolt heads strip easily . Set the beauty ring aside if you plan to reinstall it later.
Step 3: Install the Beadlock Ring
Ford Performance beadlock rings come with 24 fasteners and mounting instructions . Here’s the process from Ford Performance’s official guide :
- Release air from the tire by removing the valve stem core.
- Break the outer bead of the tire off the wheel flange.
- Apply tire soap liberally to the outer flange and bead.
- Press the beadlock ring against the tire. Make sure the valve stem cutout aligns.
- Hand-thread four bolts at the corners. Tighten each one full turn with a 13mm socket.
- Hand-thread all remaining bolts. Check that the gap between the ring and wheel is uniform all the way around.
Step 4: Torque the Beadlock Bolts
This is the critical part. Ford Performance specifies a three-stage torque sequence :
| Stage | Torque |
|---|---|
| First pass | 15 Nm (11 ft-lb) |
| Second pass | 35 Nm (25.8 ft-lb) |
| Third pass | 65 Nm (47.9 ft-lb) |
| Final check | 65 Nm (47.9 ft-lb) |
Use the torque sequence template provided with the ring. The sequence can start at any bolt, but you must follow the pattern for even clamping pressure .
Important: All bolts must be bottomed out before the sequence is complete. Check for gaps between the ring and wheel using a piece of paper or feeler gauge .
Step 5: Inflate the Tire
Stand the tire upright and inflate. Do not exceed 44 PSI. The rear bead needs to “pop” over the inboard bead hump during inflation .
Step 6: Reinstall the Wheel
Mount the wheel on the Bronco and install the lug nuts. Torque them to 135 Nm (100 lb-ft) in a star pattern .
Re-check lug nut torque within 160 km (100 miles) after any wheel removal .
Torque Specs Summary
| Fastener | Torque | Notes |
|---|---|---|
| Lug nuts (M12 x 1.5) | 135 Nm (100 lb-ft) | Re-check after 100 miles |
| Beadlock ring bolts | 65 Nm (47.9 lb-ft) | 3-stage sequence |
| Beauty ring bolts | Ford spec (not published) | Hand tools only |
Charting Bronco Wheel Specifications
The 2026 Bronco lineup uses consistent wheel specs across most trims, with the Raptor as the exception:
2026 Bronco Wheel Specifications
Torque values from Ford Performance installation guide and Ford owner’s manual specifications .
Frequently Asked Questions
Can I drive on the street with functional beadlock rings installed?
No. Ford Performance states clearly: “Converting the beadlock compatible wheel to true beadlocks is for off-road use only. On road driving is not permitted” . The beadlock configuration is not street legal in most jurisdictions.
Do I need to remove the beauty rings to change tires?
It depends on the shop. Some tire shops will work on them with the rings on. Others refuse. Forum users report both experiences. If you’re swapping tires, removing the beauty rings first makes the job easier and prevents damage .
What size are the beadlock ring bolts?
The bolt head is 13mm . Ford Performance includes 24 fasteners with each ring kit .
How often should I re-torque the beadlock bolts?
Ford Performance recommends re-checking beadlock bolt torque after 500 miles of driving. Torque them back to 65 Nm (47.9 lb-ft) .
Can I use aftermarket beadlock rings?
Ford Performance recommends using only Ford Performance beadlock rings with the OEM tire. Any other combination could result in air loss or tire failure .
What’s the maximum tire pressure for beadlock wheels?
Do not exceed 44 PSI when inflating a tire on a beadlock wheel .
Do beadlock rings come with the Bronco from the factory?
No. The Bronco comes with beauty rings installed. Functional beadlock rings are sold separately through Ford Performance. The ring kit (part number M-1021-F15RB) includes the forged aluminum ring, 24 fasteners, and mounting instructions .
Will beadlock rings fit the Bronco Raptor?
Yes, but you need the correct kit. The Ford Performance beadlock ring kit fits 2021-2026 Bronco with factory beadlock-capable wheels and 2022-2026 Bronco Raptor with the factory beadlock cast wheel option .
Always verify torque specs with your specific vehicle’s owner manual. Never exceed 44 PSI when inflating beadlock wheels. Beadlock conversions are for off-road use only.
